Introduction:
The VUFM 1671 is an LCD field strength display unit manufactured by Schwarzbeck, Germany, and is authorized by EUTTEST Shenzhen for sales and quotation service throughout the country. This display unit needs to be used in conjunction with the field strength meter VUFM 1670, which has a built-in Ni-Cd battery and requires a simple 12 V / 100 mA power supply for recharging, a wall charger ACS 110 is available on request.
Connection Instructions:
VUFM 1670 Electric Field Strength Meter Especially for quick overview measurements outside the laboratory, it is often necessary to operate from a distance and use a swinging pointer to directly indicate the measured electric field strength. On the other hand, the compact meter does not affect the electric field too much and does not pose a danger to anyone due to strong electric fields. That's why we use fiber optic links 1671 and 1670, because compared to copper wires, fiber optic links have almost no effect on the electric field. We offer fiber optics in standard lengths of up to 20 meters, and even longer test distances can be achieved if the transmitter diodes of the VUFM 1670 are supplied with more drive power.
Technical parameters:
<<<<提醒:左右滑动表格>>>>Model number | VUFM 1671 |
Device name | LCD field intensity display unit |
manufacturer | Schwarzbeck |
agent | EUTTEST |
Maximum measured field strength | 300V/m |
Adaptive Field Strength Table | VUFM 1670 |
Minimum display scale | 0.3V/m |
Display Gear | 1 V/m - 5 V/m 5 V/m - 30 V/m 50 V/m - 300 V/m |
size | 120mm*80mm*70mm |
weight | 0.45 kg |
fiber optics | 2.2mm diameter Maximum length 20 meters |
