VHA 9103 Schwarzbeck 300MHz-VHF-Half Wave Dipole Antenna

Model: VHA 9103
Brand: Schwarzbeck

Min. order: 1 unit
Stock: 0
Delivery: 1-16 weeks

Standards: /
Industry: /

Warranty: Original Import ; New Products ; Authorized Sales
Training: On-site training; Telephone; Email
Logistics: Shenzhen to National
Payment: Online banking

Product Price:

Introduction:

VHA 9103 is a 300MHz-VHF-half-wave dipole antenna manufactured by Schwarzbeck, Germany, and is authorized to be represented by EUTTEST Shenzhen for sales and quotation services. The tunable half-wave dipole antenna VHA9103 contains two pairs of variable length dipole antenna elements, which can be varied in the range of 0.485m to 5m in length, and the test frequency covers 30MHz-300MHz after adjusting the length of LE as shown in the figure below, which is mainly used for EMC test.

The VHA 9103 can vary the antenna length from 0.485m to 5m.

Antenna length can be varied from 0.485m to 5m.

To generate high field strengths, we recommend the use of a 4:1 balancer/bracket VHBA 9123 (50 W),VHBC 9133 (1 kW),VHBD 9134 (2.4 kW) or VHBD 9134-4 (4kW), which offer excellent efficacy and power ratings, especially in the low frequency range.

Technical parameters:

<<<<提醒:左右滑动表格>>>>
Antenna ModelVHA 9103
manufacturerSchwarzbeck
agentShenzhen EUTTEST
Test Frequency30MHz-300MHz
Number of dipole elements4
Dipole antenna width0.495 m to 5 m adjustable
baron decay (physics)0.25dB to 6dB
Antenna Coefficient-2.1 dB/m to 18.2 dB/m
Antenna Gain+1.5dBi
Maximum input power10W
weight0.93 kg
connectorN
<<<<提醒:左右滑动表格>>>>

Graph of related technical parameters:

Antenna Gain Profile of VHA 9103 300MHz-VHF-Half Wave Dipole Antenna

Antenna Gain Graph
