Introduction:
RE 4590 is a vertically polarized VHF-UHF biconical antenna produced by SCHWARZBECK company from Germany, represented by Shenzhen EUTTEST sales and quotation service, this omni-directional antenna can be tested in the frequency range of 450MHz-1GHz, the maximum input power of 200W, the shipment of this antenna will be provided with the entire frequency range of the magnetic field - the test frequency range for EMC test personnel reference. Omni-directional antenna direction diagram for EMC testers to refer to the use of the RE4590 and RE 1790 is the difference between the antenna size is smaller, antenna 4590 antenna width is only 1790 antenna half of the size of the detailed dimensions of the table below the technical parameters.
If you need an omni-directional antenna above 1GHz, please purchase it:RS 16 vertically polarized omnidirectional biconical antenna
Technical parameters:
<<<<提醒:左右滑动表格>>>>Antenna Model | RE 4590 |
manufacturer | Schwarzbeck Germany |
agent | EUTTEST Shenzhen |
Antenna name | Vertical Polarization VHF-UHF Biconical Antenna |
Recommended Test Frequency Range | 450MHz-1000MHz |
Available Test Frequency Range | 330MHz-1100MHz |
connector | 50Ω impedance N female connector |
Tube Diameter | 22mm |
Antenna Gain Range | -2dBi to 1.5dBi |
Antenna Coefficient Range | 25dB/m to 30dB/m |
Maximum input power | 200W |
Half-power beamwidth | 80°-50° |
weight | 950 grams |
size | 140mm*140mm*225mm |
Antenna Height | 760mm |
Graph of related technical parameters:

Antenna Coefficient Graph
