RE 1790 Schwarzbeck Vertical Polarized VHF-UHF Biconical Antenna

Model: RE 1790
Brand: Schwarzbeck

Min. order: 1 unit
Stock: 0
Delivery: 1-16 weeks

Standards: /
Industry: /

Warranty: Original Import ; New Products ; Authorized Sales
Training: On-site training; Telephone; Email
Logistics: Shenzhen to National
Payment: Online banking

Product Price:

Introduction:

RE 1790 is a vertically polarized VHF-UHF biconical antenna produced by SCHWARZBECK company from Germany, which is represented by Shenzhen EUTTEST for sales and quotation service, this omnidirectional antenna can be used for testing in the frequency range of 230MHz-1GHz, with a maximum input power of 200W, and when shipped, we will provide the magnetic field of this antenna for the whole testing frequency range. Omni-directional antenna direction diagram for EMC testers reference.

If you need an omni-directional antenna above 1GHz, please purchase it:RS 16 vertically polarized omnidirectional biconical antenna

Technical parameters:

<<<<提醒:左右滑动表格>>>>
Antenna ModelRE 1790
manufacturerSchwarzbeck Germany
agentEUTTEST Shenzhen
Antenna nameVertically Polarized VHF-UHFBiconical antenna
Recommended Test Frequency Range230MHz-1000MHz
Available Test Frequency Range170MHz-1100MHz
connector50Ω impedance N female connector
Tube Diameter22mm
Antenna Gain Range-3dBi to 2.5dBi
Antenna Coefficient Range20dB/m to 33dB/m
Maximum input power200W
Half-power beamwidth80°-50°
weight950 grams
size250mm*250mm*450mm
Antenna Height760mm
<<<<提醒:左右滑动表格>>>>

Graph of related technical parameters:

RE 1790 Schwarzbeck Antenna Gain Plot for a Vertically Polarized VHF-UHF Biconical Antenna

Antenna Gain Graph
