ILS Dipole Schwarzbeck ILS Tests Half-Wave Dipole Antennas

Model: ILS Dipole
Brand: Schwarzbeck

Min. order: 1 unit
Stock: 0
Delivery: 1-16 weeks

Standards: /
Industry: /

Warranty: Original Import ; New Products ; Authorized Sales
Training: On-site training; Telephone; Email
Logistics: Shenzhen to National
Payment: Online banking

Product Price:

Introduction:

The ILS Dipole is a linearly polarized ILS test half-wave dipole antenna manufactured by Schwarzbeck and authorized for sale and quotation by EUTTEST Shenzhen. This dipole antenna is designed for field strength testing of Instrument Landing Systems (ILS) from 108MHz-118MHz and 320MHz-340MHz and can be used with the AM 9144 Antenna bracket fixing antenna test.

Technical parameters:

<<<<提醒:左右滑动表格>>>>
Product modelILS Dipole
manufacturerSchwarzbeck
agentShenzhen EUTTEST
Test Frequency108MHz-118MHz

320MHz-340MHz

Antenna Gain1.5dBi
radiance factor10-19dB/m
impedance50Ω
standing wave ratio (physics)<2
3dB bandwidth80°
connectorBNC

Optional N-type connector

weight0.8 kg
size0.43m-1.43m
<<<<提醒:左右滑动表格>>>>

Graph of related technical parameters:

Antenna Gain Plot for ILS Dipole Antennas

Antenna gain plot for dipole antenna

Antenna Coefficient Plot for ILS Dipole Dipole Antennas

Plot of antenna coefficients of dipole antenna
