IGUF 2910 Schwarzbeck High Power Pulse Generator

Model: IGUF 2910
Brand: Schwarzbeck

Min. order: 1 unit
Stock: 0
Delivery: 1-16 weeks

Standards: /
Industry: /

Warranty: Original Import ; New Products ; Authorized Sales
Training: On-site training; Telephone; Email
Logistics: Shenzhen to National
Payment: Online banking

Product Price:

Introduction:

IGUF 2910 is a high power pulse generator produced by Schwarzbeck, Germany and represented by EUTTEST Shenzhen for sales quotation and after sales service. This signal source and IGUU 2916IGUU 2918 \ IGLK 2914 \ IGU 2912 is widely used worldwide for pulse signal generation and calibration purposes.

This antenna can be used with a VHF or UHF antenna for spatial attenuation testing of ERP effective radiated power, or with a dipole antenna.

Configuration of the IGUF 2910 for spatial attenuation testing of ERP effective radiated power with VHF or UHF antennas

Configuration diagram for spatial attenuation testing of ERP effective radiated power with VHF or UHF antennas

Equipment Features:

  • Compact and battery operated generator
  • Coaxial shielded DC power cord to power the unit
  • Can be used with all impedance matched antennas via 50Ω connector outputs
  • Battery-driven without cable interference
  • Easy receiver tuning due to broadband spectrum design
  • High pulse repetition frequency allows for human-recognizable sounds
  • Very high pulse power: 1.8 kW at 50 ohms
  • Pulse flat spectrum: 300 MHz/1 dB, 1 GHz/6 dB



Technical parameters:

<<<<提醒:左右滑动表格>>>>
Model numberIGUF 2910

IGUF 2910 S , old model

manufacturerSchwarzbeck
agentEUTTEST
Voltage value displayed on the CISPR 2/4 receiver QPK80 dBμV±1dB
Voltage value displayed on the CISPR 1 receiver QP62 dBμV
Voltage value displayed on the MIL True peak receiver62 dBμV /MHz
No-load pulse voltage600V
Pulse voltage on 50Ω load300V
Product of pulse voltage and duration0,3 μv/sec
pulse power1.8kW
pulse period0.5ns
Pulse Repetition Frequency250Hz
Pulse frequency range1MHz-300MHz
Supply Battery12V

Provision of chargers

<<<<提醒:左右滑动表格>>>>
