HI-6153 U.S.A. ETS-Lindgren Omnidirectional Broadband Electric Field Probe 40GHz 800Vm

Model: HI-6153
Brand: ETS-Lindgren

Min. order: 1 unit
Stock: 0
Delivery: 1-16 weeks

Standards: /
Industry: /

Warranty: Original Import ; New Products ; Authorized Sales
Training: On-site training; Telephone; Email
Logistics: Shenzhen to National
Payment: Online banking

Product Price:

What is HI-6153?

ETS-Lindgren's Model HI-6153 Laser-Driven Electric Field Probe provides broadband EMF frequency coverage and a wide dynamic range to meet most test requirements. To take advantage of this capability, the HI-6153 RF Field Probe is designed for single-range readout so that data can be read continuously over the entire dynamic range. Data values for each axis (X, Y, Z) can be read individually or summed.

HI-6153 Test Method:

Testers can connect the Model HI-6153 probe to the Model HI-6100 Field Monitor using fiber optic signal and power cables, or directly to PC USB Port™ laser software with the HI-6113 laser data interface and ProbeView.

The HI-6100 provides manual functions and programmed control via IEEE-488 and RS-232 serial data interfaces. Up to four probe readings can be displayed simultaneously.

E-Commerce Center™ Modular RF Platform and EMSense™ In addition to functioning as a system-level platform, the interface card can be used as a field monitor with the HI-6000 series field probes.

The HI-6113 provides laser power and communications for the HI-6153. A USB connection to a PC allows for quick and easy data collection using the ProbeView laser software.

How to buy HI-6153?

EUTTEST Shenzhen EUTTEST Technology Co., Ltd. is the agent of ETS-LINDGREN, and can provide consulting service for all the products price and delivery period of ETS company.

2023: HI-6153 Discontinued. Please select the battery-powered HI-6053 below:

HI-6053 Battery Powered Electric Field Probe Frequency Range 10 MHz-40 GHz

The main technical parameters of HI-6153:

<<<<提醒:左右滑动表格>>>>
Model numberHI-6153
manufacturerETS Lindgren
Agents in ChinaShenzhen EUTTEST
Sensor typeelectric field
sensingIsotropic (X, Y, Z axis readings)
Frequency range10MHz-40GHz
accurate±2.5dB (10MHz-18GHz), +2.0dB/-4.0dB (18-40GHz)
dynamic range2.0-800V/m
resolution (of a photo)0.01V/m
concentric deviation±1.0dB
Readout unitsV/m, V2/m2mW/cm2
biometrics±0.5dB
sampling rate>70 times per second
overloaded>1500V/m CW
optical interfaceDual Fiber (62.5μm Multimode), FC Interface
operating temperature10 - 40°C
relative humidity5%-95% non-condensing
size43.2cmx10.2cm
weight540g
<<<<提醒:左右滑动表格>>>>

Charts related to technical parameters:

 Frequency Response Curve of HI-6153

Frequency Response Curve of HI-6153
