HA 9250-48 Standard Gain Horn Antenna for Schwarzbeck 8GHz

Name: HA 9250-48
Brand: Schwarzbeck
SKU: ha-9250-48
Price: 1392 CNY
Availability: PreOrder
Rating: 4.8 (15 reviews)

Model: HA 9250-48

Type: Standard gain horn antenna

Brand: Schwarzbeck

Min. order: 1 unit

Stock: 0

Delivery: 1-16 weeks

Standards: /

Industry： /

Warranty: Original Import ; New Products ; Authorized Sales

Training: On-site training; Telephone; Email

Logistics: Shenzhen to National

Payment: Online banking

Product Price:

Introduction：

HA 9250-48 is a standard gain horn antenna from Schwarzbeck, Germany, which is distributed by us. It is a horn antenna with linear polarization direction and Schwarzbeck configured the antenna with 7/16 or N type input connector, which ensures that EMC testers can inject 500W of RF power in the frequency range of 4-8GHz.

Technical parameters：

<<<<提醒：左右滑动表格>>>>

Model number	HA 9250-48
manufacturer	Schwarzbeck Schwarzbeck (name)
agent	Shenzhen EUTTEST
Test frequency range	3.7 GHz - 9 GHz
Antenna Gain	20 dBi
radiance factor	23-30 dB/m
6dB wave width	22-24°
Maximum input power	500 W
Antenna Mounting Adapter	AM9144
Antenna Size	226303695 mm
weight	1.7 kg

<<<<提醒：左右滑动表格>>>>

HA9250-24 Gain Curve Diagram:

Antenna Gain Graph

Other optional antenna products of the same sequence:

This antenna is one of Schwarzbeck's HA 9250 serial horn antennas. If this antenna does not meet your requirements, we offer the following antennas as options:

HA 9250-12 Test frequency 1 GHz - 2 GHz.
HA 9250-24 Test frequency 2 GHz - 4 GHz.
HA 9250-818 Test frequency 8 GHz - 18 GHz.
