FSE3D Schwarzbeck 3GHz Handheld Electric Field Probe

Model: FSE3D
Brand: Schwarzbeck

Min. order: 1 unit
Stock: 0
Delivery: 1-16 weeks

Standards: /
Industry: /

Warranty: Original Import ; New Products ; Authorized Sales
Training: On-site training; Telephone; Email
Logistics: Shenzhen to National
Payment: Online banking

Product Price:

Introduction:

FSE3D is a 3 GHz handheld electric field probe manufactured by Schwarzbeck, Germany and authorized by EUTTEST Shenzhen for sales and quotation service. The probe has a test frequency range of (10) 30 MHz - 3 (3.3) GHz, is lightweight with low attenuation, and has an outer diameter of approximately 150 mm. This handheld electric field probe consists of three identical active broadband dipoles arranged perpendicular to each other. At the rear is a shielded unit containing the switching and amplifier circuitry, which is connected directly to the N-type outputs and provides power and logic signals via Binder-connectors, which select the dipole to be turned on. The pin assignment allows use with the FSH 3/6 and FSH 4/8, popular handheld spectrum analyzers from Rohde & Schwarz. The RF transparent radome protects the probe from dust and moisture. Due to its lightweight construction, the probe can be mounted directly on the spectrum analyzer. In addition, the FSE3D can be fixed manually by means of a 50 mm shaft (sweep method) or by means of a 22 mm tube on a mast or tripod (rotary or grating method).

If you want to measure the magnetic field, please purchase Schwarzbeck FSH3D

Technical parameters:

<<<<提醒:左右滑动表格>>>>
Model numberFSE3D
manufacturerSchwarzbeck
agentShenzhen EUTTEST
Test frequency range30MHz-3GHz
Maximum Test Frequency Range10MHz-3.3GHz
connectorN-shape
power supply5V DC
Power supply connectorsBinder 99-0421-10-07
Electric field antenna coefficient26 dB/m to 33 dB/m
standing wave ratio (physics)1.3-1.7
1dB compression point30 MHz: 142.5 dBµV/m

300 MHz: 141.0 dBµV/m

size550 mm * 146 mm * 146 mm
weight0.82 kg
Optional charging connectorODU MINI-SNAP S21L0C-P06MFD0-6200
<<<<提醒:左右滑动表格>>>>

Graph of related technical parameters:

Antenna Coefficient Plot for FSE3D Measured Electric Field

Plot of antenna coefficients for measured electric fields
