Introduction：
FMZB 1519-60 C is a ring antenna with active magnetic field newly produced and launched by Schwarzbeck, Germany in 2024, authorized by Shenzhen EUTTES agent for sales, quotation and after-sales service.
You can also choose the latest 60cm loop antenna: FMZB 1519-60 D Meets the requirements of the latest CISPR 16-1-4 Ed4 and future versions of the standard.
difference：
FMZB 1519-60 C Yes FMZB 1519 C A variant of the FMZB 1519 C, it has a larger antenna diameter of 60 cm than the 50 cm of the 1519 C. This is suitable for special test requirements where the antenna diameter of 60 cm is required, e.g. for CISPR32 standards. Apart from the diameter, the other parameters of this loop antenna are the same as those of the FMZB 1519 C, so it can also be mounted on a tripod AM9144 or a hand-held grip, also with built-in rechargeable Ni-MH battery, overload indicator for remote monitoring, and a detachable 180 mm glass fiber grip optimized for mobility.
Technical parameters：
<<<<提醒：左右滑动表格>>>>| Antenna Model | FMZB 1519-60 C |
| producers | Schwarzbeck |
| agent | Euttest |
| Test Frequency | 9kHz-30MHz |
| Antenna Diameter | 60cm (0.6m) |
| Field Strength Measurement Range - 9kHz IF Bandwidth | 30-140 dBμV/m (1MHz) |
| Field strength measurement range - 200Hz IF bandwidth | 8-140 dBμV/m (1MHz) |
| Antenna factor (battery and magnetic field) | Figure 1 |
| 1dB compression point field strength | Figure 2 |
| frequency response | ±1dB |
| standing wave ratio (physics) | <2 |
| running time | >12 hours. |
| Supply Battery | 12V NiMH 1.9 Ah |
| Antenna bracket adapter thread | 3/8 inch, 1/4 inch |
| Antenna Mount Adapter | Customized by EUTTEST |
| Hand Held Handle Mounting Threads | 3/8 in. |
| Handle Adapter | Customized by EUTTEST |
| size | 630mm*690mm*110mm |
| weight | 2.0 kg |
| Optional accessories | CCA 1519-60 C ACS 110 AA 9202 22mm tube 3/8 38 x 500 mm, 3/8″ 38 x 180 mm, 3/8″ Fiber Optic Controlled Remote Overload Indicator: Opt. FMZB RSM Kit |
Graph of related technical parameters：
Figure 1: Antenna Coefficient Plot of FMZB1519-60C Measured Magnetic Field and Battery
Figure 2: 1dB Compression Point Field Strength Curve of FMZB1519-60C
