Introduction：
FCC-BCICF-150-1 is an injected current probe calibration fixture manufactured by FCC Fischer Custom Communications, Inc. and authorized for sale by EUTTEST Shenzhen. Test frequency: 2.3 GHz - 7.0 GHz, suitable for F-150-1 calibration test.
Most high current injection test program specifications require that an injection probe calibration fixture be part of the test equipment. This test fixture, FCC-BCICF-150-1, allows the user to quickly and easily calibrate the injection probe prior to performing conformance testing. Contact us for current probe calibration methods after purchasing this calibration fixture from EUTTEST.
The FCC-BCICF-150-1 calibration fixture offers two important advantages:
1. Due to variable circuit impedance or resonance in the cable, calibration fixtures are used to build positive power into the injection probe to produce a specified current in the system under test.
2. The fixture can be used to measure the insertion loss of the injection probe.
FCC-BCICF-150-1 Technical Data:
<<<<提醒：左右滑动表格>>>>| Calibration Fixture Model | FCC-BCICF-150-1 |
| Applicable current probe type | High Current Injection Probes |
| agent | Shenzhen EUTTEST |
| frequency of use | 2.3 GHz - 7.0 GHz |
| size | (L x W x H) 102 mm x 76 mm x 64 mm |
| weight | 2.3kg |
VSWR for FCC-BCICF-150-1
