CDN for FCC-801-T2-RJ11 2-pin network port

Model: FCC-801-T2-RJ11
Brand: FCC

Min. order: 1 unit
Stock: 0
Delivery: 1-16 weeks

Standards:
Industry: /

Warranty: Original Import ; New Products ; Authorized Sales
Training: On-site training; Telephone; Email
Logistics: Shenzhen to National
Payment: Online banking

Product Price:

Introduction:

FCC-801-T2-RJ11 is a U.S. FCC company produced for the DUT with 2-pin RJ11 network port for conducted common mode immunity test, the coupling decoupling network can only be used for unshielded network port test, and only 2 by the D-sub25 to the network port of the pins available, the coupling decoupling network to support the maximum current input of 400mA, the product This product by the Shenzhen YiYuTe company in the national scope of agent sales and quotation service.

Technical parameters:

<<<<提醒:左右滑动表格>>>>
Product modelFCC-801-T2-RJ11
manufacturerUnited States FCC
agentShenzhen EUTTEST
Test Frequency150kHz-230MHz
Number of signal lines4 articles
Common mode impedance150kHz-26MHz Frequency: 150Ω ±20Ω

At 26MHz-80MHz: 150Ω +60Ω / -45Ω

At 80MHz-230MHz frequency: 150Ω ±60Ω

Meets standard requirementsIEC 61000-4-6, Clause 6.2, Form 3 Requirements

IEC 61000-4-6, Appendix B, Form B.1 requirements

Maximum current400mA
Maximum voltageAC: 100V RMS

DC: 100V

EUT Port ConnectorDsub-25 Female Connector to T2 WA-EUT-1/2 RJ11
AE Port ConnectorDsub-25 Female Connector to T2 WA-EUT-1/2 RJ11
RF Port Impedance50Ω
Maximum Conducted Injection Voltage30V Full Frequency Range
<<<<提醒:左右滑动表格>>>>

Recommendations for similar products:

The following CDNs are also configured with network ports, click on the product link for more information:
