FBAB 9177 + VHBA 9123 Schwarzbeck 100W Open Biconical Antenna

Name: fbab 9177 + vhba 9123
Brand: Schwarzbeck
SKU: fbab-9177-vhba-9123
Price: 2292 CNY
Availability: PreOrder
Rating: 4.8 (15 reviews)

FBAB 9177 + VHBA 9123 Antenna Factor Plot for Radiated Emission Testing

Model: fbab 9177 + vhba 9123

Type: Biconical antenna

Brand: Schwarzbeck

Min. order: 1 unit

Stock: 0

Delivery: 1-16 weeks

Standards: /

Industry： /

Warranty: Original Import ; New Products ; Authorized Sales

Training: On-site training; Telephone; Email

Logistics: Shenzhen to National

Payment: Online banking

Product Price:

Introduction：

FBAB 9177 + VHBA 9123 is a 100W open biconical antenna combination manufactured by Schwarzbeck, Germany, which is sold and quoted by Shenzhen Eutectic. This antenna consists of the Barron VHBA 9123 and the antenna element FBAB 9177, and it can input a maximum power of 100W. It is recommended to use this antenna if it is used for radiated nuisance testing. If used for radiated nuisance testing, it is recommended to use the antenna at a frequency of not more than 50MHz, because its antenna coefficient will become very poor when it exceeds 50MHz.

Technical parameters：

<<<<提醒：左右滑动表格>>>>

Model number	fbab 9177 + vhba 9123
manufacturer	Schwarzbeck
agent	EUTTEST
Device name	Biconical antenna
impedance	50Ω
Maximum input power	100W
Palombia	50/200Ω
polarize	biometrics
Antenna Size	1.22 m* 0.6 m
radiance factor	8-22 dB/m
Antenna Gain	-18 to 2 dBi
Test Frequency	25MHz-320MHz
weight	1.1 kg
Recommended antenna mounts	AM 9144

<<<<提醒：左右滑动表格>>>>

Graph of related technical parameters：

Antenna Coefficient Plot for Radiated Emission Testing
