F-42A Introduction:
F-42A is an EMI monitoring current probe manufactured by FCC (Fischer Custom Communications, Inc.) and authorized to be sold by EUTTEST Shenzhen. The F-42A is used for laboratory and field testing. Available Frequency RangeThe frequency of this probe is 1kHz-100MHz.Typical calibration curves are shown below. The probe has a small outer diameter of about 71 mm and an inner diameter of 32 mm.
F-42A Main technical parameters:
Available frequency range: 1 kHz - 100 MHz
Internal ring diameter: 32 mm
Outer ring diameter:71mm
Height. 19mm;
Typical ZtΩ(1)4；
Typical dBΩ. 12;
Connectors. N, 50 ohms;
额定功率电流值: 50 A (DC - 400 Hz);
RF (CW continuous wave):2A;
Peak pulse current (2): 100A;
1: Calibrate the probe with a 50Ω+j0Ω load impedance.
2: Depends on pulse width and pulse repetition rate.
F-42A Calibration Fixture: FCC-MPCF-3-32/71/19
Transmission Impedance Curve of F-42A
FCC: Product specifications are subject to change without notice.
Product specifications are subject to change without notice.
