F-220114-1005-1 FCC 1GHz Current Monitoring Probe

Name: F-220114-1005-1
Brand: FCC
SKU: f-220114-1005-1
Price: 2944 CNY
Availability: PreOrder
Rating: 4.8 (15 reviews)

Transmission Impedance Curve for Current Monitoring Probe F-220114-1005-1

Model: F-220114-1005-1

Type: Current probe-monitor

Brand: FCC

Min. order: 1 unit

Stock: 0

Delivery: 1-16 weeks

Standards: /

Industry： /

Warranty: Original Import ; New Products ; Authorized Sales

Training: On-site training; Telephone; Email

Logistics: Shenzhen to National

Payment: Online banking

Product Price:

Introduction：

F-220114-1005-1 is produced by the U.S. FCC manufacturer and authorized by the Shenzhen EUTTEST agent sales of 1GHz current monitoring probe, can be used for electronic products on the power line of the 10 kHz - 1GHz conductive emission common mode nuisance current measurement. The probe can be used to obtain RF current components directly on the cable to be tested, providing specific data on the transmission path and level of the high frequency signal on the cable. We recommend that you use this probe to rectify EMC emission problems in your electronic products and it is used in the laboratory by EUTTEST trained RF technicians using best engineering practices.

Technical parameters：

<<<<提醒：左右滑动表格>>>>

Current Probe Model	F-220114-1005-1
manufacturer	FCC
Domestic Authorized Agents	Shenzhen EUTTEST
frequency	10kHz-1GHz
Inner ring diameter	32mm
Outer ring diameter	71mm
high degree	19mm
Transmission impedance ZtΩ	1
Transmission Impedance dBΩ	0
connector	N
DC-400Hz Current	400A
RF continuous wave current	3A
pulse current (physics)	100A
Calibration Fixture	fcc-mpcf-3-32-40/71/19

<<<<提醒：左右滑动表格>>>>

Transmission impedance graph:

Transmission Impedance Curve
