CTIA 0710 Schwarzbeck Dual Polarized Horn Antenna

Model: CTIA 0710
Brand: Schwarzbeck

Min. order: 1 unit
Stock: 0
Delivery: 1-16 weeks

Standards: /
Industry: /

Warranty: Original Import ; New Products ; Authorized Sales
Training: On-site training; Telephone; Email
Logistics: Shenzhen to National
Payment: Online banking

Product Price:

Introduction:

CTIA 0710 is a dual-polarized horn antenna made of aluminum alloy by SCHWARZBECK, Germany, and is authorized to be sold by EUTTEST in Shenzhen, China for quotation and after-sales service. This antenna has the function of dual-polarized receiving or transmitting at the same time, equipped with high-frequency SMA connector, we recommend our customers to carry out the antenna OTA test in the range of 0.7GHz-10GHz for the TIS total omni-directional sensitivity, TRP total radiated power, and NHPRP near-horizontal portion of the radiated power and other test items.

Technical parameters:

<<<<提醒:左右滑动表格>>>>
Model numberCTIA 0710
Antenna nameDual polarized Broadband Horn Antennas
manufacturerSchwarzbeck
agentEUTTEST
Frequency range0.7GHz-10GHz
isotropic gain5 -13 dBi (frequency > 1 GHz)
radiance factor25-39 dB/m (frequency > 1 GHz)
impedance50 Ω
SWR2
SWR max.1.25 GHz)
port isolationtyp. > 30 dB
cross-polarizationtyp. > 25 dB
3dB wave E-plane40-80°
3dB wave H-plane40-140°
Maximum input power100 W (short-time power)

50 W (continuous power)

connectorSMA mother
size235 x 200 x 235 mm
weight0.84 kg
Option - 22mm mounting tube220 x 22 mm
Option-Antenna MountAM 9144
<<<<提醒:左右滑动表格>>>>

Curve diagrams related to the technical parameters of the CTIA0710:

Isotropic Gain Curve for CTIA 0710

Isotropic Gain Curve

Antenna Coefficient Plot for CTIA 0710

Antenna Coefficient Graph
