BBAL 9136 + HFBA 9122 Schwarzbeck Biconical antenna for high electric field strength tests

Name: bbal 9136 + hfba 9122
Brand: Schwarzbeck
SKU: bbal-9136-hfba-9122
Price: 2800 CNY
Availability: PreOrder
Rating: 4.8 (15 reviews)

Model: bbal 9136 + hfba 9122

Type: Biconical antenna

Brand: Schwarzbeck

Min. order: 1 unit

Stock: 0

Delivery: 1-16 weeks

Standards: /

Industry： /

Warranty: Original Import ; New Products ; Authorized Sales

Training: On-site training; Telephone; Email

Logistics: Shenzhen to National

Payment: Online banking

Product Price:

Introduction：

BBAL 9136 + HFBA 9122 is a high field strength test biconical antenna combination from Schwarzbeck, Germany, which can be used for high field strength test in the frequency range of 20MHz-220MHz, and the maximum can be used up to 500MHz, but the field strength test intensity will be reduced. Above 50MHz the antenna gain will tend to stabilize, this high field strength test biconical antenna by Shenzhen EUTTEST agent sales and provide quotation consulting service.

Technical data for BBAL 9136 and HFBA 9122:

<<<<提醒：左右滑动表格>>>>

Combination Antenna Model	bbal 9136 + hfba 9122
Antenna name	Biconical antenna
manufacturer	Schwarzbeck
agent	EUTTEST
Test Frequency	20MHz-200MHz
impedance	50Ω
output connector	N-head
Antenna width	1.85 meters
weight	0.9 kg
Antenna Gain Range	-22dBi to 0dBi
Antenna Coefficient Range	3.5dB/m to 20dB/m
Antenna bracket	AM 9144

<<<<提醒：左右滑动表格>>>>

Graph of related technical parameters：

Coefficient profile of a biconical antenna

We will provide the antenna coefficients of this antenna for 1 meter test distance and 3 meter test distance in the darkroom in the shipment, which you can directly input into the EMI test software for automated test use.

Service

Our company sells all the instrumentation equipment products provide after-sales personnel door-to-door training or telephone, e-mail, microblogging and other ways of installation and training services.

We are committed to supplying equipment that is brand new and manufactured by the original manufacturers at home and abroad.

After-sales of the product is carried out by the after-sales policy provided by the original equipment manufacturer.

Purchase

The EUTTEST website does not sell any products online and is only used to display information about the products that our company represents and sells or researches in-house.

The prices shown are for display purposes only, please contact our sales staff to get the real-time quotation information of the required instruments and equipment products;

When you confirm your purchase, we will contact you to sign a purchase and sales contract.

Our company only deals with companies and provides formal Chinese VAT special invoices.
